Description
The Powermatic® 3520C is the fourth evolution of the time honored lathe with many new and improved features. The 3520C has retained all the features of the prior models such as the sliding headstock, electronic variable speed with low and high speed ranges, the spindle lock, digital RPM readout, and a laser etched quill that is self-ejecting. The enhanced features include a movable control box for maximum versatility, adjustable riser blocks for 6 inches or more of height adjustment, and an increased weight of 726 LBS (814 LBS with the bed extension). Additional features include a new ergonomic spindle lock design, a digital indexing readout, an Anti-rotation tailstock key for smoother operation, a set of dead centers which hold a spindle for visual comparison, a two position mount for the optional bed extension, and a sliding hammer knockout rod with brass tip.
FEATURES
Moveable control box for customizable versatility
Main power disconnect switch located on rear of headstock
Self-locating ergonomic spindle lock design for easy, one handed operation
Upgraded banjo features a non-marring, pinch style clamp for solid tool rest placement
Extended spindle nose increased access to the work piece
Adjustable Risers Blocks for 6-inches of height adjustment allowing maximum comfort when turning
Tailstock incorporates Anti-rotation key and Acme threads for smoother operation and increased longevity
Digital Indexing Readout simplifies the indexing process for added precision
Fully enclosed VFD for increased user protection
Able to maintain speeds as low as 15 RPM
Increased Weight to 726LBS (814LBS with bed extension) for the most stable turning experience possible
Increased working capacity to a full 35 inches between centers
Optional safety shield
Following strict guidelines and electrical requirements, these Powermatic 3520C Lathes are CSA Certified
SPECIFICATIONS
Swing Over Tool Rest Base (In.)
15-3/4
Distance Between Centers (In.)
36 w/dual bearing center
Headstock Movement
Full Length of Bed
Ram Travel Quill Travel
4-1/2″
Spindle Threads (In. x TPI)
1-1/4 x 8
Outboard External Threads (In. x TPI)
1-3/16-18UNC
Spindle Speeds
Low 15-1200/High 40-3200
Number of Indexing Positions
48
Centerline of Spindle to Floor (In.)
40-5/8 without Risers
Bed Construction
Cast Iron
Motor Voltage (V.)
230 Only
Prewired Voltage (V.)
230 Only
Wiring Remarks
Single Phase ONLY
Recommended Circuit Size (Amps.)
20
