Description
This 6″ Jointer features a helical cutterhead with 40 four-sided indexable carbide knife inserts – this design provides a superior finish and quieter operation compared to conventional cutterheads, and the inserts require no adjustment once they are installed. If a knife insert becomes nicked, simply rotate it for a fresh edge and continue working. Oversized infeed/outfeed tables are mounted on dovetailed ways. The fence is 38″ in length, with positive stops at 90° and 45° right and left. The fine/quick adjustment lever on the infeed table offers quick set-ups with precision controlled depth of cut. The heavy steel stand features a 1 HP motor with a non-slip v-belt drive for maximum performance. The 4″ dust port offers easy connection to any dust collection system.
FEATURES
Helical cutterhead with 4-sided carbide inserts provides smoother, quieter cutting and finer finish than conventional systems
66″ long adjustable infeed and outfeed tables provide more working surface
Fine/quick adjustment lever on infeed table for precision cuts
Extra-long 38″ two-way tilting fence with positive stops provides quick positioning for 90° or bevel cuts
Enlarged sheet metal stand provides a sturdy base
1HP motor offers plenty of power
Fence controls are center-mounted for convenience
Push button switch is lockable to prevent accidental starting
4″ port for dust collection
Standard Equipment:
1HP TEFC Motor
Two push blocks
Dust collection port
Cutterhead guard
Industrial push-button switch
SPECIFICATIONS
Helical Knife Size (L x W x T) (In.)
15 x 15 x 2.5
Cutterhead Speed (RPM)
6,000
Cutting Capacity (W x D) (In.)
6 x 1/2
Table Size (L x W) (In.)
66 x 7-1/4
Table Height from Floor (In.)
31-1/2
Infeed Table Length (In.)
32-1/2
Outfeed Table Length (In.)
32-1/2
Rabbeting Capacity (In.)
NA
Fence Size (L x H) (In.)
38 x 4
Fence Tilt (Deg.)
45 Forward, 45 Backward
Fence Positive Stops (Deg.)
45, 90, -45
Dust Collection Minimum CFM Required (CFM)
450
Dust Port Outside Diameter (In.)
4
Motor Voltage (V.)
115/230
Prewired Voltage (V.)
115
Motor Current (Amps)
13/6.5
Recommended Circuit Size (Amps.)
20/10
Call for pricing (978) 667-1911
