Description
FEATURES
- Available in Right Hand & Left Hand configuration
- Cutting off capacity (thickness x width): 2″ x 12″, 3″ x 11″, 4″ x 10″
- Powerful 10HP main motor
- Pneumatic foot pedal operation with adjustable cutting speed from the front of the machine
- Fast cutting rate up to 45 strokes per minute.
- Cast iron table surface is precision ground assuring high cutting accuracy.
- Safety blade guard with adjustable fingers for added safety.
- Material clamp is easily adjusted for workpiece thickness variation.
- CSA magnetic switch
Door safety limit switch with 3” long screw
| Cutting capacity (thickness x width) | 2″ x 12″, 3″ x 11″, 4″ x 10″ |
| Cycle speed | 45 strokes/min |
| Cycle operation | Air |
| Saw blade size (optional) | 18″ |
| Saw arbor diameter | 1″ |
| Saw blade speed | 3600 RPM |
| Dust exhaust diameter | Ø4″ (100mm) |
| Motor | 10 HP |
| Table size | 26” x 27 ½” (660 x 700 mm) |
| Net weight | 770 lbs. (350 kgs) |
| Gross weight | 902 lbs. (410 kgs) |
| Packing dimensions (L x W x H) | 37” x 33 ½” x 53.2” (940 x 850 x 1350mm) |
PCS-18-D, 18″ pneumatic chop saw with safety dual buttons in lieu of foot pedal (LH or RH)
