Description
Features:
- Heavy-duty cast iron table is precision ground for accuracy
- Rugged machine frame construction provides maximum stability & reduced vibration
- Precision rip fence assembly locks on front rail for a precise parallel reference to the saw blade
- Dual Inch/Metric scale guide rail on rip fence with magnifying glass for easy visibility
- Heavy-duty cast iron saw assembly
- Saw guard with safety anti-kickback
- Mitre gauge with 2 mitre slots in table
- Two handwheels for blade tilting, raising/lowering with locking knobs
- CSA magnetic switch with overload protection
- Less saw blade
Specifications:
| Diameter saw blade | 12″ |
| Max. depth of cut at 90° | 4″ |
| Max. depth of cut at 45° | 2 3/4″ |
| Arbor diameter | 1″ |
| Arbor speed | 4000 RPM |
| Table size | 48″x30″ |
| Table height | 34 1/4″ |
| Max. rip to right of blade | 50″ |
| Motor | 5HP |
| Electrics | 230/3/60 |
| Net weight | 572lb |
| Gross weight | 704lb |
| Packing size | 32″x36″x42″h |
